Specifications
Dimensions: 13,000mm * 2,500mm * 3,800mm (Standard Dimensions, Customizable)
Payload:100 tons, Customizable
Main beam : Up20/Middle 1mm/Down 20mm
Axles: 3 axles *25 T, Customizable
Dump Style: Rear Dump, Customizable to Side Dump
Cylinder: HYVA (model depends on container length)
Main Beam Material: Q345/T700
Tires: 11.00R20/12R22.5 * 8/12/16 pieces
Suspension: Mechanical or Air Suspension
Leaf Springs: 90mm*16mm*10 pieces
Landing Gear: 28T, Two-speed, JOST
King Pin: #50(2″)/#90(3.5″), JOST/other brands
Additional Customizable Options: Paint process, ABS, Reflective Tape, LED lights, etc.
